MOON W-8 RS

€4.500,00

ype	Solid State
Configuration	Dual-Mono / Fully Balanced
Power Supply Transformers	2 x 1.3kVA
Power Supply Capacitance	240,000µF
Class Of Operation	A/AB
Balanced Inputs	XLR – 1 pair
Single-ended Inputs	RCA – 1 pair
Input Device Type	J-FETs
Input Impedance	47.5 KΩ
Input Sensitivity	1260mV RMS
Output Device Type	Bipolars – 16 per channel
Output Binding Posts	WBT – 2 pairs
Output Power @ 8 Ω	250 Watts
Output Power @ 4 Ω	500 Watts
Output Power @ 2 Ω	1000 Watts
Output Power – Bridged Mono	1000 Watts
Frequency Response	10Hz – 200kHz (+0/-3dB)
Output Impedance	< 0.01
Damping Factor (static)	> 800
Gain	31dB
Signal-to-noise Ratio	106dB @ full power
Maximum Output Voltage	50 Volts
Slew Rate	42 V/µs
Maximum Current – Peak	64 amperes
Maximum Current – Continuous	26 amperes
Crosstalk @ 1kHz	-105dB
IMD	Unmeasureable
THD (20Hz – 20kHz @ 1 watt)	0.015 %
THD (20Hz – 20kHz @ 250 watts)	0.04 %

12 Volt Trigger Operation	Direct Logic (0V = off, 12V=on) using a 1/8" mini-jack with an input impedance of 1K Ω and current requirement of 12mA
RS-232 Port	9-pin female DB connector

Power Consumption @ idle	50 watts
AC Power Requirements	120V / 60Hz 240V / 50Hz
Fuse Replacement – 120V	10A long fast blow
Fuse Replacement – 230V	5A long fast blow
Shipping weight	92 lbs / 42 kgs
Dimensions (w x h x d)	18.8 x 7.4 x 17.5 in.
